这个和上一个差不多，简单说下：
1.因为NEW是在创建搜索界面的时候加的，所以此时只需在结果界面重定义NEW事件：
method EH_ONNEW.
OP_NEW( ).
endmethod.
2.结果界面创建外向插件NEW
METHOD OP_NEW. DATA: LR_WINDOW TYPE REF TO CL_BSP_WD_WINDOW. LR_WINDOW = ME->VIEW_MANAGER->GET_WINDOW_CONTROLLER( ). LR_WINDOW->CALL_OUTBOUND_PLUG( ‘NEWTODETAIL‘ ). ENDMETHOD.
3.WINDOW界面，创建外向插件NEWTODETAIL
METHOD OP_NEWTODETAIL. FIRE_OUTBOUND_PLUG( IV_OUTBOUND_PLUG = ‘NEWTODETAIL‘ ). ENDMETHOD.
查询组件结束，开始明细组件ZLYTEST03_H
1.WINDOW创建内向插件：FROMNEW
METHOD IP_FROMNEW. VIEW_MANAGER->NAVIGATE( SOURCE_REP_VIEW = REP_VIEW OUTBOUND_PLUG = ‘LINKTODETAIL‘ ). ENDMETHOD.
2.WINDOW中创建外向插件：LINKTODETAIL
3.概览页中创建内向插件FROMMAINWD（因为查询没有用BOL的查询，所以都是以VALUE NODE处理的，此处是给个初始化值）
DATA: LR_REF_ANY TYPE REF TO DATA, GW_EKKO TYPE EKKO, LR_VALUE_NODE TYPE REF TO CL_BSP_WD_VALUE_NODE. GET REFERENCE OF GW_EKKO INTO LR_REF_ANY. CREATE OBJECT LR_VALUE_NODE TYPE CL_BSP_WD_VALUE_NODE EXPORTING IV_DATA_REF = LR_REF_ANY. ME->TYPED_CONTEXT->RESULT->COLLECTION_WRAPPER->ADD( LR_VALUE_NODE ). ENDMETHOD.
如果是BOL，则用下面的：
METHOD IP_FROMMAINWD. DATA:LR_CORE TYPE REF TO CL_CRM_BOL_CORE. DATA:LR_FACTORY TYPE REF TO CL_CRM_BOL_ENTITY_FACTORY. DATA:LR_DETAIL TYPE REF TO CL_CRM_BOL_ENTITY. DATA:LS_PARAMS TYPE CRMT_NAME_VALUE_PAIR, GW_EKKO TYPE EKKO, LT_PARAMS TYPE CRMT_NAME_VALUE_PAIR_TAB. DATA:LR_FOUND TYPE REF TO IF_BOL_BO_PROPERTY_ACCESS. ME->TYPED_CONTEXT->DETAIL2->COLLECTION_WRAPPER->CLEAR( ). LS_PARAMS-NAME = ‘EBELN‘. LS_PARAMS-VALUE = ‘4200000999‘. APPEND LS_PARAMS TO LT_PARAMS. LR_CORE = CL_CRM_BOL_CORE=>GET_INSTANCE( ). LR_FACTORY = LR_CORE->GET_ENTITY_FACTORY( ‘ZEKKO‘ ). LR_DETAIL = LR_FACTORY->CREATE( LT_PARAMS ). CHECK LR_DETAIL IS BOUND. ME->TYPED_CONTEXT->DETAIL2->COLLECTION_WRAPPER->ADD( IV_ENTITY = LR_DETAIL IV_SET_FOCUS = ABAP_TRUE ). IF LR_FOUND IS INITIAL. ME->TYPED_CONTEXT->DETAIL2->COLLECTION_WRAPPER->ADD( IV_ENTITY = LR_DETAIL IV_SET_FOCUS = ABAP_TRUE ). ENDIF. CALL METHOD ME->SET_VIEW_GROUP_CONTEXT EXPORTING IV_PARENT_CONTEXT = VIEW_GROUP_CONTEXT IV_FIRST_TIME = ABAP_TRUE. ME->VIEW_GROUP_CONTEXT->SET_ALL_EDITABLE( ). ENDMETHOD.
4.运行时中，创建NavigationalLinks LINKTODETAIL 丛WINDOW到概览页。
到这里，明细组件也完成了。。。取MAIN组件
1.创建NavigationalLink NEWTODETAIL 。。。。
完成。。。
原文：http://www.cnblogs.com/sapSB/p/6340522.html
