Provider pattern allows the developers to create pluggable components. It was first introduced in framework 2.0 and it has lot of features like "Membership Provider", "Roles Provider" etc. and instantiates using configuration file.
This article provides guidelines to create logging component using provider pattern. The sample project contains two providers "TextLogProvider" and "XmlLogProvider" You can set one of them default in configuration file.
First of all you need to define abstract representation of all your methods. Create your data provider base class and your class must inherit from System.Configuration.Provider.ProviderBase base class.
Hide???Copy Code
public
abstract
class LogProviderBase : ProviderBase
{
.
public
abstract
void WriteLog(LogType logType, string message);
.
}
As you see?LogProviderBase?is an abstract class and it has abstract method?WriteLog(..). In this example we have only one abstract method. But we can have more than one as per requirement.
After creating your base provider class, now you can create your concrete provider classes. In this sample I will create two providers for logging one for text and second for xml. Derive concrete provider class from LogProviderBase class and implement the abstract methods.
Hide???Shrink?
???Copy Code
public
class TextLogProvider : LogProviderBase
{
?
#region Data Members
?
private
string _filePath = "";
?
#endregion
?
#region Overrided Methods
?
public
override
void SetParameters(System.Collections.Specialized.NameValueCollection config)
{
_filePath = config["fileLocation"];
}
?
public
override
void WriteLog(LogType logType, string message)
{
var dir = Path.GetDirectoryName(_filePath);
if (!Directory.Exists(dir))
Directory.CreateDirectory(dir);
?
using (var sw = new StreamWriter(_filePath, true))
{
string s = string.Format("{0}, {1}, {2}", DateTime.Now, logType.ToString(), message);
sw.WriteLine(s);
}
}
?
#endregion
?
}
Write the logging logic according to your provider type by implementing?WriteLog(…). In?TextLogProviderclass i am saving CVS line in text file.
For taking care of the provider configuration, you must write your own provider collection class derived from?System.Configuration.ProviderCollection?class.?ProviderCollection?class exposes properties and methods to work with the list of various data providers declared in your configuration file.
Hide???Copy Code
public
class LogProviderCollection : ProviderCollection
{
new
public LogProviderBase this[string name]
{
get { return (LogProviderBase)base[name]; }
}
}
Provider pattern reads the concrete providers from the configuration file, for this purpose you need one more class which will read all the provider collections from the configuration file. Create?ProviderConfiguration?class derived from the?System.Configuration.ConfigurationSection?file.
Hide???Copy Code
public
class LogProviderConfiguration : ConfigurationSection
{
?
[ConfigurationProperty("providers")]
public ProviderSettingsCollection Providers
{
get
{
return (ProviderSettingsCollection)base["providers"];
}
}
?
[ConfigurationProperty("default", DefaultValue = "XmlProvider")]
public
string DefaultProviderName
{
get
{
return
base["default"] as
string;
}
}
?
}
In this class you can add as many properties based on the different parameters that you need to extract from the configuration sections. All the properties must be decorated with the?ConfigurationProperty?attribute.
For configuring the provider model, we need to define our provider configuration section in?<configsections>. Here we can add a?<section>?element with the name of the provider model configuration section element and the type of our data provider configuration class.
After configuring section (we configured LogProviders as section name). Now we need to add our all available providers in it and set one default provider from them.
Hide???Copy Code
<configSections>
<section
name="LogProviders"
type="ProviderPatternLogTest.LogProvider.LogProviderConfiguration, ProviderPatternLogTest"/>
</configSections>
?
?
<LogProviders
default="XmlProvider">
<providers>
?
<add
name="XmlProvider"
type="ProviderPatternLogTest.LogProvider.Providers.XmlLogProvider, ProviderPatternLogTest"
fileLocation="c:\temp\log.xml"/>
?
<add
name="TextProvider"
type="ProviderPatternLogTest.LogProvider.Providers.TextLogProvider, ProviderPatternLogTest"
fileLocation="c:\temp\log.txt"/>
?
</providers>
</LogProviders>
It is very easy to use provider model in your code, simply get the default property of Provider Manager Class and then call your concrete methods
Hide???Copy Code
LogProviderManager.Default.WriteLog(logType, txtMessage.Text);
You can also easily get other useful information of your concrete provider. Simply get ProviderSetting using LogProviderManager.
Hide???Copy Code
var setting = LogProviderManager.ProviderSettings[defaultName];
?
var setStr = GetSetting(setting);
?
MessageBox.Show(setStr);
GetSetting(...)?method only parse all the parameters and returns concatenated string message.
Hide???Copy Code
private
string GetSetting(ProviderSettings setting)
{
StringBuilder str = new StringBuilder();
str.AppendLine(string.Format("Default Provider name: {0}", setting.Name));
str.AppendLine(string.Format("Default Provider type: {0}", setting.Type));
str.AppendLine("------------------Parameters--------------------");
foreach (String s in setting.Parameters)
{
?
str.AppendLine(string.Format("Parameter: {0} -> {1}", s, setting.Parameters.Get(s)));
}
str.AppendLine("---------------------------------------");
str.AppendLine("");
?
return str.ToString();
}
?
From: https://www.codeproject.com/Articles/550495/Provider-Pattern-for-Beginners
Provider Pattern for Beginners in .net
原文：http://www.cnblogs.com/time-is-life/p/6349250.html
