Vue+SSM+Element-Ui实现前后端分离(2)

时间：2019-08-02 10:33:07 阅读：167 评论：0 收藏：0 [点我收藏+]

　　前言：后台使用ssm搭建，对以前学习知识的一个回顾，与此同时来发现自己不足。这里主要采用配置文件方式进行，有部分注解。

　　目标：搭建ssm框架，并测试成功；（其中也有aop切面的编写）

一、开发工具

　　IDEA2018.2.4_X64，MYSQL8.0.11，TOMCAT9.0.22，MAVEN3.5.3，JDK1.8.0_144

二、ssm框架搭建

　　项目结构图

技术分享图片

　1、配置文件（这里不多说，里面有详细注释）

  1 <?xml version="1.0" encoding="UTF-8"?>
  2
  3 <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
  4   xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
  5   <modelVersion>4.0.0</modelVersion>
  6
  7   <groupId>com.wzz</groupId>
  8   <artifactId>SSM</artifactId>
  9   <version>1.0-SNAPSHOT</version>
 10   <packaging>war</packaging>
 11
 12   <name>SSM Maven Webapp</name>
 13   <!-- FIXME change it to the project‘s website -->
 14   <url>http://www.example.com</url>
 15
 16   <properties>
 17     <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
 18     <maven.compiler.source>1.8</maven.compiler.source>
 19     <maven.compiler.target>1.8</maven.compiler.target>
 20     <spring.version>5.0.2.RELEASE</spring.version>
 21     <slf4j.version>1.6.6</slf4j.version>
 22     <log4j.version>1.2.12</log4j.version>
 23     <shiro.version>1.2.3</shiro.version>
 24     <mysql.version>8.0.11</mysql.version>
 25     <mybatis.version>3.4.5</mybatis.version>
 26   </properties>
 27
 28   <dependencies>
 29     <!--Spring提供的对AspectJ框架的整合-->
 30     <dependency>
 31       <groupId>org.aspectj</groupId>
 32       <artifactId>aspectjweaver</artifactId>
 33       <version>1.6.8</version>
 34     </dependency>
 35     <!--Spring的面向切面编程，提供AOP（面向切面编程）的实现-->
 36     <dependency>
 37       <groupId>org.springframework</groupId>
 38       <artifactId>spring-aop</artifactId>
 39       <version>${spring.version}</version>
 40     </dependency>
 41
 42     <!--Spring IOC的基础实现，包含访问配置文件、创建和管理bean等-->
 43     <dependency>
 44       <groupId>org.springframework</groupId>
 45       <artifactId>spring-beans</artifactId>
 46       <version>${spring.version}</version>
 47     </dependency>
 48     <!--在基础IOC功能上提供扩展服务，此外还提供许多企业级服务的支持，
 49       有邮件服务、任务调度、JNDI定位，EJB集成、远程访问、缓存以及多种视图层框架的支持-->
 50     <dependency>
 51       <groupId>org.springframework</groupId>
 52       <artifactId>spring-context</artifactId>
 53       <version>${spring.version}</version>
 54     </dependency>
 55     <!--Spring context的扩展支持，用于MVC方面-->
 56     <dependency>
 57       <groupId>org.springframework</groupId>
 58       <artifactId>spring-context-support</artifactId>
 59       <version>${spring.version}</version>
 60     </dependency>
 61     <!--Spring的核心工具包-->
 62     <dependency>
 63       <groupId>org.springframework</groupId>
 64       <artifactId>spring-core</artifactId>
 65       <version>${spring.version}</version>
 66     </dependency>
 67     <!--spring的jdbc包-->
 68     <dependency>
 69       <groupId>org.springframework</groupId>
 70       <artifactId>spring-jdbc</artifactId>
 71       <version>${spring.version}</version>
 72     </dependency>
 73     <!--为JDBC、Hibernate、JDO、JPA等提供的一致的声明式和编程式事务管理-->
 74     <dependency>
 75       <groupId>org.springframework</groupId>
 76       <artifactId>spring-tx</artifactId>
 77       <version>${spring.version}</version>
 78     </dependency>
 79
 80     <!--包含Web应用开发时，用到Spring框架时所需的核心类，
 81       包括自动载入WebApplicationContext特性的类、Struts与JSF集成类、文件上传的支持类、Filter类和大量工具辅助类-->
 82     <dependency>
 83       <groupId>org.springframework</groupId>
 84       <artifactId>spring-web</artifactId>
 85       <version>${spring.version}</version>
 86     </dependency>
 87     <!--包含SpringMVC框架相关的所有类。
 88     包含国际化、标签、Theme、视图展现的FreeMarker、JasperReports、Tiles、Velocity、XSLT相关类。
 89     当然，如果你的应用使用了独立的MVC框架，则无需这个JAR文件里的任何类-->
 90     <dependency>
 91       <groupId>org.springframework</groupId>
 92       <artifactId>spring-webmvc</artifactId>
 93       <version>${spring.version}</version>
 94     </dependency>
 95     <!--对JUNIT等测试框架的简单封装-->
 96     <dependency>
 97       <groupId>org.springframework</groupId>
 98       <artifactId>spring-test</artifactId>
 99       <version>${spring.version}</version>
100     </dependency>
101     <!--servlet-->
102     <dependency>
103       <groupId>javax.servlet</groupId>
104       <artifactId>servlet-api</artifactId>
105       <version>2.5</version>
106       <scope>provided</scope>
107     </dependency>
108
109     <!--mysql驱动包-->
110     <dependency>
111       <groupId>mysql</groupId>
112       <artifactId>mysql-connector-java</artifactId>
113       <version>${mysql.version}</version>
114     </dependency>
115     <!--mybatis-->
116     <dependency>
117       <groupId>org.mybatis</groupId>
118       <artifactId>mybatis</artifactId>
119       <version>${mybatis.version}</version>
120     </dependency>
121     <!--mybatis与spring整合需要的包 -->
122     <dependency>
123       <groupId>org.mybatis</groupId>
124       <artifactId>mybatis-spring</artifactId>
125       <version>1.3.0</version>
126     </dependency>
127
128     <!--mybatis分页插件-->
129     <dependency>
130       <groupId>com.github.pagehelper</groupId>
131       <artifactId>pagehelper</artifactId>
132       <version>5.1.10</version>
133     </dependency>
134
135     <!--c3p0-->
136     <dependency>
137       <groupId>c3p0</groupId>
138       <artifactId>c3p0</artifactId>
139       <version>0.9.1.2</version>
140       <type>jar</type>
141       <scope>compile</scope>
142     </dependency>
143
144     <!--spring推荐的json转化包-->
145     <!--jackson-->
146     <dependency>
147       <groupId>com.fasterxml.jackson.core</groupId>
148       <artifactId>jackson-databind</artifactId>
149       <version>2.9.0</version>
150     </dependency>
151     <dependency>
152       <groupId>com.fasterxml.jackson.core</groupId>
153       <artifactId>jackson-core</artifactId>
154       <version>2.9.0</version>
155     </dependency>
156     <dependency>
157       <groupId>com.fasterxml.jackson.core</groupId>
158       <artifactId>jackson-annotations</artifactId>
159       <version>2.9.0</version>
160     </dependency>
161
162     <!--阿里巴巴的json转化包-->
163     <!--fastjson-->
164     <dependency>
165       <groupId>com.alibaba</groupId>
166       <artifactId>fastjson</artifactId>
167       <version>1.1.37</version>
168     </dependency>
169
170
171     <!--浏览器工具类-->
172     <dependency>
173       <groupId>eu.bitwalker</groupId>
174       <artifactId>UserAgentUtils</artifactId>
175       <version>1.20</version>
176     </dependency>
177
178     <!-- 日志相关包 -->
179     <dependency>
180       <groupId>log4j</groupId>
181       <artifactId>log4j</artifactId>
182       <version>${log4j.version}</version>
183     </dependency>
184     <dependency>
185       <groupId>org.slf4j</groupId>
186       <artifactId>slf4j-api</artifactId>
187       <version>${slf4j.version}</version>
188     </dependency>
189     <dependency>
190       <groupId>org.slf4j</groupId>
191       <artifactId>slf4j-log4j12</artifactId>
192       <version>${slf4j.version}</version>
193     </dependency>
194
195     <dependency>
196       <groupId>junit</groupId>
197       <artifactId>junit</artifactId>
198       <version>4.11</version>
199       <scope>compile</scope>
200     </dependency>
201   </dependencies>
202
203   <build>
204     <finalName>SSM</finalName>
205     <!--编译时，使得java包下的.properties和.xml文件包含在类路径下，方便配置扫描mapper的xml文件-->
206     <resources>
207       <resource>
208         <directory>src/main/java</directory>
209         <includes>
210           <include>**/*.properties</include>
211           <include>**/*.xml</include>
212         </includes>
213         <filtering>false</filtering>
214       </resource>
215     </resources>
216
217     <pluginManagement><!-- lock down plugins versions to avoid using Maven defaults (may be moved to parent pom) -->
218       <plugins>
219         <plugin>
220           <artifactId>maven-clean-plugin</artifactId>
221           <version>3.1.0</version>
222         </plugin>
223         <!-- see http://maven.apache.org/ref/current/maven-core/default-bindings.html#Plugin_bindings_for_war_packaging -->
224         <plugin>
225           <artifactId>maven-resources-plugin</artifactId>
226           <version>3.0.2</version>
227         </plugin>
228         <plugin>
229           <artifactId>maven-compiler-plugin</artifactId>
230           <version>3.8.0</version>
231         </plugin>
232         <plugin>
233           <artifactId>maven-surefire-plugin</artifactId>
234           <version>2.22.1</version>
235         </plugin>
236         <plugin>
237           <artifactId>maven-war-plugin</artifactId>
238           <version>3.2.2</version>
239         </plugin>
240         <plugin>
241           <artifactId>maven-install-plugin</artifactId>
242           <version>2.5.2</version>
243         </plugin>
244         <plugin>
245           <artifactId>maven-deploy-plugin</artifactId>
246           <version>2.8.2</version>
247         </plugin>
248       </plugins>
249     </pluginManagement>
250   </build>
251 </project>

pom.xml

 1 <?xml version="1.0" encoding="UTF-8"?>
 2 <beans xmlns="http://www.springframework.org/schema/beans"
 3        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 4        xmlns:aop="http://www.springframework.org/schema/aop"
 5        xmlns:tx="http://www.springframework.org/schema/tx"
 6        xmlns:context="http://www.springframework.org/schema/context"
 7        xsi:schemaLocation="http://www.springframework.org/schema/beans
 8          http://www.springframework.org/schema/beans/spring-beans.xsd
 9          http://www.springframework.org/schema/tx
10          http://www.springframework.org/schema/tx/spring-tx.xsd
11          http://www.springframework.org/schema/aop
12          http://www.springframework.org/schema/aop/spring-aop.xsd
13          http://www.springframework.org/schema/context
14          http://www.springframework.org/schema/context/spring-context.xsd">
15
16     <!--开启注解扫描，因为spring和springMVC是父子容器，但是它们有各自独立性，这里排除Controller层，如果不排除，都全部扫描，就可能会出现Controller的方法无法拦截、Bean被多次加载等问题；-->
17     <context:component-scan base-package="com.wzz">
18         <context:exclude-filter type="annotation" expression="org.springframework.stereotype.Controller"/>
19     </context:component-scan>
20     <!--spring整合mybatis-->
21     <context:property-placeholder location="classpath:db.properties"/>
22     <!--配置连接池-->
23     <bean id="dataSource" class="com.mchange.v2.c3p0.ComboPooledDataSource">
24         <property name="driverClass" value="${jdbc.driver}"/>
25         <property name="jdbcUrl" value="${jdbc.url}"/>
26         <property name="user" value="${jdbc.userName}"/>
27         <property name="password" value="${jdbc.password}"/>
28         <property name="initialPoolSize" value="${jdbc.c3p0.initialPoolSize}"/>
29         <property name="maxPoolSize" value="${jdbc.c3p0.maxPoolSize}"/>
30         <property name="minPoolSize" value="${jdbc.c3p0.minPoolSize}"/>
31         <property name="maxIdleTime" value="${jdbc.c3p0.maxIdleTime}"/>
32     </bean>
33     <!--配置SqlSessionFactory对象-->
34     <bean id="sqlSessionFactory" class="org.mybatis.spring.SqlSessionFactoryBean">
35         <property name="dataSource" ref="dataSource"/>
36         <property name="configLocation" value="classpath:sqlMapConfig.xml"/>
37         <property name="mapperLocations" value="classpath:com/wzz/mapper/*.xml"/>
38         <!--配置mybatis分页插件-->
39         <property name="plugins">
40             <array>
41                 <bean class="com.github.pagehelper.PageInterceptor">
42                     <property name="properties">
43                         <props>
44                             <prop key="helperDialect">mysql</prop>
45                             <prop key="reasonable">true</prop>
46                         </props>
47                     </property>
48                 </bean>
49             </array>
50         </property>
51     </bean>
52     <!--配置接口所在的包-->
53     <bean id="mapperScanner" class="org.mybatis.spring.mapper.MapperScannerConfigurer">
54         <property name="basePackage" value="com.wzz.mapper"/>
55     </bean>
56     <!--配置spring框架声明式事务管理-->
57     <!--配置事务管理器-->
58     <bean id="transactionManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
59         <property name="dataSource" ref="dataSource"/>
60     </bean>
61     <!--配置事务通知-->
62     <tx:advice id="txAdvice" transaction-manager="transactionManager">
63         <!--事务的属性-->
64         <tx:attributes>
65             <!--SUPPORTS代表支持当前事务，如果当前没有事务，就以非事务方式执行。-->
66             <tx:method name="query*" propagation="SUPPORTS" read-only="true"/>
67             <!--DEFAULT代表以数据库的隔离级别-->
68             <tx:method name="*" isolation="DEFAULT"/>
69         </tx:attributes>
70     </tx:advice>
71     <!--配置Aop增强-->
72     <aop:config>
73         <!--配置切入点表达式-->
74         <!--* *..*.*(..)      修饰符（可省略）   返回类型  包.包....包.类.方法.(参数)-->
75         <aop:pointcut id="pt" expression="execution(* com.wzz.service.impl.*.*(..))"/>
76         <!--建立事务与切入点之间的关系-->
77         <aop:advisor advice-ref="txAdvice" pointcut-ref="pt"/>
78     </aop:config>
79 </beans>

applicationContext.xml

 1 <?xml version="1.0" encoding="UTF-8"?>
 2 <beans xmlns="http://www.springframework.org/schema/beans"
 3        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 4        xmlns:aop="http://www.springframework.org/schema/aop"
 5        xmlns:context="http://www.springframework.org/schema/context"
 6        xmlns:mvc="http://www.springframework.org/schema/mvc"
 7        xsi:schemaLocation="http://www.springframework.org/schema/beans
 8          http://www.springframework.org/schema/beans/spring-beans.xsd
 9          http://www.springframework.org/schema/mvc
10          http://www.springframework.org/schema/mvc/spring-mvc.xsd
11          http://www.springframework.org/schema/aop
12          http://www.springframework.org/schema/aop/spring-aop.xsd
13          http://www.springframework.org/schema/context
14          http://www.springframework.org/schema/context/spring-context.xsd">
15     <!--springMVC值扫描controller-->
16     <context:component-scan base-package="com.wzz.controller"/>
17
18     <!--配置日志切面-->
19     <aop:config>
20         <aop:pointcut id="pt" expression="execution(* com.wzz.controller.*.*(..))"/>
21         <!--日志切面-->
22         <aop:aspect id="" ref="sysAccessLogAspect">
23             <!--前置通知-->
24             <aop:before method="doBefore" pointcut-ref="pt"></aop:before>
25             <!--后置通知-->
26             <aop:after-returning method="doAfter" pointcut-ref="pt"></aop:after-returning>
27         </aop:aspect>
28     </aop:config>
29
30     <!--视图解析器
31         这里不需要视图解析器，因为不处理jsp，或者html,咱们是前后端分离，后端只负责返回数据即可-->
32     <!--<bean id="internalResourceViewResolver" class="org.springframework.web.servlet.view.InternalResourceViewResolver">-->
33     <!--<property name="prefix" value="/WEB-INF/pages/"/>-->
34     <!--<property name="suffix" value=".jsp"/>-->
35     <!--</bean>-->
36     <!--&lt;!&ndash;过滤静态资源&ndash;&gt;-->
37     <!--<mvc:resources mapping="/css/**" location="/css/"/>-->
38     <!--<mvc:resources mapping="/images/**" location="/images/"/>-->
39     <!--<mvc:resources mapping="/js/**" location="/js/"/>-->
40
41     <!--springMVC框架流程
42     1、 用户发起请求到前端控制器（DispatcherServlet），前端控制器没有能力处理业务逻辑；
43     2、 通过HandlerMapping查找模型（Controller、Handler）；
44     3、 返回执行链，执行链包含了2部分内容，Handler对象以及拦截器（组）；
45     4、 通过HandlerAdapter执行模型（Handler）
46     5、 适配器调用Handler对象处理业务逻辑；
47     6、 模型处理完业务逻辑，返回ModelAndView对象，view不是真正的视图对象，而是视图名称；
48     7、 将ModelAndView对象返回给前端控制器；
49     8、 前端控制器通过视图名称经过视图解析器查找视图对象；
50     9、 返回视图对象；
51     10、前端控制器渲染视图；
52     11、返回给前端控制器；
53     12、前端控制器将视图（html、json、xml、Excel）返回给用户；-->
54
55
56     <!--开启springMVC注解支持-->
57     <mvc:annotation-driven/>
58 </beans>

springMVC.xml

　　这里我当时有一个疑问，springMVC.xml为什么要配置注解驱动？现在我知道了，你知道吗？ <-_->

　　不错的解释 https://blog.csdn.net/weixin_42529699/article/details/88085405

 1 <?xml version="1.0" encoding="UTF-8" ?>
 2 <!DOCTYPE configuration
 3         PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
 4         "http://mybatis.org/dtd/mybatis-3-config.dtd">
 5 <configuration>
 6     <!--别名配置   对model包下的所有起一个别名，默认是它的类名（不分大小写）-->
 7     <typeAliases>
 8         <package name="com.wzz.model"/>
 9     </typeAliases>
10 </configuration>

sqlMapConfig.xml

 1 log4j.rootLogger=DEBUG,Console,File
 2 log4j.appender.Console=org.apache.log4j.ConsoleAppender
 3 log4j.appender.Console.Target=System.out
 4 log4j.appender.Console.layout = org.apache.log4j.PatternLayout
 5 log4j.appender.Console.layout.ConversionPattern=[%c] - %m%n
 6 log4j.appender.File =org.apache.log4j.RollingFileAppender
 7 log4j.appender.File.File = logs/SSM.log
 8 log4j.appender.File.MaxFileSize = 10MB
 9 log4j.appender.File.Threshold = ALL
10 log4j.appender.File.layout =org.apache.log4j.PatternLayout
11 log4j.appender.File.layout.ConversionPattern =[%p] [%d{yyyy-MM-ddHH\\\:mm\\\:ss}][%c]%m%n
12 log4j.logger.java.sql.ResultSet=DEBUG
13 log4j.logger.java.sql.Connection=DEBUG
14 log4j.logger.java.sql.PreparedStatement=DEBUG

log4j.properties

 1 jdbc.driver=com.mysql.cj.jdbc.Driver
 2 jdbc.url=jdbc:mysql://localhost:3306/ssm?serverTimezone=GMT%2B8&useSSL=false
 3 jdbc.userName=wzz
 4 jdbc.password=521125
 5 #---------------------------------------------------------
 6 # c3p0反空闲设置，防止8小时失效问题28800
 7 #---------------------------------------------------------
 8 #idleConnectionTestPeriod要小于MySQL的wait_timeout
 9 #If true, an operation will be performed at every connection checkout to verify that the connection is valid.
10 jdbc.c3p0.testConnectionOnCheckout=false
11 #If true, an operation will be performed asynchronously at every connection checkin to verify that the connection is valid.
12 jdbc.c3p0.testConnectionOnCheckin=true
13 #If this is a number greater than 0, c3p0 will test all idle, pooled but unchecked-out connections, every this number of seconds.
14 jdbc.c3p0.idleConnectionTestPeriod=3600
15 #---------------------------------------------------------
16 # c3p0连接池配置
17 #---------------------------------------------------------
18 #initialPoolSize, minPoolSize, maxPoolSize define the number of Connections that will be pooled.
19 #Please ensure that minPoolSize <= maxPoolSize.
20 #Unreasonable values of initialPoolSize will be ignored, and minPoolSize will be used instead.
21 jdbc.c3p0.initialPoolSize=10
22 jdbc.c3p0.minPoolSize=10
23 jdbc.c3p0.maxPoolSize=50
24 #maxIdleTime defines how many seconds a Connection should be permitted to go unused before being culled from the pool.
25 jdbc.c3p0.maxIdleTime=3600

db.properties

 1 <!DOCTYPE web-app PUBLIC
 2  "-//Sun Microsystems, Inc.//DTD Web Application 2.3//EN"
 3  "http://java.sun.com/dtd/web-app_2_3.dtd" >
 4
 5 <web-app>
 6   <display-name>Archetype Created Web Application</display-name>
 7   <!--配置spring的监听器，默认加载WEB-INF目录下的applicationContext.xml配置文件-->
 8   <listener>
 9     <listener-class>org.springframework.web.context.ContextLoaderListener</listener-class>
10   </listener>
11   <!--设置配置文件的路径-->
12   <context-param>
13     <param-name>contextConfigLocation</param-name>
14     <param-value>classpath:applicationContext.xml</param-value>
15   </context-param>
16   <!--配置前段控制器-->
17   <servlet>
18     <servlet-name>dispatcherServlet</servlet-name>
19     <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
20     <!--加载springMVC.xml配置文件-->
21     <init-param>
22       <param-name>contextConfigLocation</param-name>
23       <param-value>classpath:springMVC.xml</param-value>
24     </init-param>
25     <!--contextLoaderListener监听器初始化完毕后，开始初始化web.xml中配置的Servlet，servlet可以配置多个，加载顺序按照load-on-startup的值，值越小，servlet的优先级越高，就越先被加载-->
26     <load-on-startup>1</load-on-startup>
27   </servlet>
28   <servlet-mapping>
29     <servlet-name>dispatcherServlet</servlet-name>
30     <url-pattern>/</url-pattern>
31   </servlet-mapping>
32   <!--解决中文乱码过滤器-->
33   <filter>
34     <filter-name>characterEncodingFilter</filter-name>
35     <filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class>
36     <init-param>
37       <param-name>encoding</param-name>
38       <param-value>UTF-8</param-value>
39     </init-param>
40   </filter>
41   <filter-mapping>
42     <filter-name>characterEncodingFilter</filter-name>
43     <url-pattern>/*</url-pattern>
44   </filter-mapping>
45 </web-app>

web.xml

　　2、源码文件(按结构图，从上往下出场）

 1 package com.wzz.aspect;
 2
 3 import org.aspectj.lang.JoinPoint;
 4 import org.springframework.stereotype.Component;
 5
 6 /**
 7  * @ClassName SysAccessLogAspect
 8  * @Description TODO 系统访问日志切面类
 9  * @Author wangZhenZhong
10  * Version 1.0
11  **/
12 @Component
13 public class SysAccessLogAspect {
14
15     public void doBefore(JoinPoint jp){
16         System.out.println("前置通知执行啦");
17     }
18
19     public void doAfter(JoinPoint jp){
20         System.out.println("后置通知执行啦");
21     }
22 }

SysAccessLogAspect.java

 1 package com.wzz.controller;
 2
 3 import com.wzz.service.IUserService;
 4 import org.springframework.beans.factory.annotation.Autowired;
 5 import org.springframework.stereotype.Controller;
 6 import org.springframework.web.bind.annotation.RequestMapping;
 7 import org.springframework.web.bind.annotation.ResponseBody;
 8
 9 import java.util.Map;
10
11 /**
12  * @ClassName UserController
13  * @Description TODO 用户控制层
14  * @Author AZhen
15  * Version 1.0
16  **/
17 @Controller
18 public class UserController {
19     @Autowired
20     private IUserService userService;
21
22     @RequestMapping("/test")
23     @ResponseBody
24     public Map queryUserList(){
25         System.out.println("controller层执行啦");
26         Map<String, Object> resultMap = userService.queryUserList();
27         return resultMap;
28     }
29 }

UserController.java

 1 package com.wzz.mapper;
 2
 3 import com.wzz.model.User;
 4
 5 import java.util.List;
 6
 7 /**
 8  * @ClassName UserMapper
 9  * @Description TODO 用户持久层接口
10  * @Author AZhen
11  * Version 1.0
12  **/
13 public interface UserMapper {
14     List<User> queryUserList();
15 }

UserMapper.java

 1 <?xml version="1.0" encoding="UTF-8" ?>
 2 <!DOCTYPE mapper
 3         PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
 4         "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
 5 <mapper namespace="com.wzz.mapper.UserMapper">
 6     <!--因为在sqlMapConfig.xml中配置了别名，所以直接写user就可以-->
 7     <select id="queryUserList" resultType="user">
 8         select * from tbUser
 9     </select>
10 </mapper>

UserMapper.xml

 1 package com.wzz.model;
 2
 3 import java.io.Serializable;
 4
 5 /**
 6  * @ClassName User
 7  * @Description TODO  用户类
 8  * @Author AZhen
 9  * Version 1.0
10  **/
11 public class User implements Serializable {
12     private String uid;    //uid
13     private String userName;   //用户名
14     private String password;    //密码
15     private String name;      //姓名
16     private Integer age;    //年龄
17     private Integer sex;    //性别
18
19     public String getUid() {
20         return uid;
21     }
22
23     public void setUid(String uid) {
24         this.uid = uid;
25     }
26
27     public String getUserName() {
28         return userName;
29     }
30
31     public void setUserName(String userName) {
32         this.userName = userName;
33     }
34
35     public String getPassword() {
36         return password;
37     }
38
39     public void setPassword(String password) {
40         this.password = password;
41     }
42
43     public String getName() {
44         return name;
45     }
46
47     public void setName(String name) {
48         this.name = name;
49     }
50
51     public Integer getAge() {
52         return age;
53     }
54
55     public void setAge(Integer age) {
56         this.age = age;
57     }
58
59     public Integer getSex() {
60         return sex;
61     }
62
63     public void setSex(Integer sex) {
64         this.sex = sex;
65     }
66
67     @Override
68     public String toString() {
69         return "User{" +
70                 "uid=‘" + uid + ‘\‘‘ +
71                 ", userName=‘" + userName + ‘\‘‘ +
72                 ", password=‘" + password + ‘\‘‘ +
73                 ", name=‘" + name + ‘\‘‘ +
74                 ", age=" + age +
75                 ", sex=" + sex +
76                 ‘}‘;
77     }
78 }

User.java

 1 package com.wzz.service.impl;
 2
 3 import com.wzz.mapper.UserMapper;
 4 import com.wzz.model.User;
 5 import com.wzz.service.IUserService;
 6 import org.springframework.beans.factory.annotation.Autowired;
 7 import org.springframework.stereotype.Service;
 8
 9 import java.util.HashMap;
10 import java.util.List;
11 import java.util.Map;
12
13 /**
14  * @ClassName UserServiceImpl
15  * @Description TODO  用户业务层实现类
16  * @Author AZhen
17  * Version 1.0
18  **/
19 @Service
20 public class UserServiceImpl implements IUserService {
21     @Autowired
22     private UserMapper userMapper;
23     @Override
24     public Map<String,Object> queryUserList() {
25         System.out.println("service执行啦");
26         List<User> userList = userMapper.queryUserList();
27         System.out.println("调用了mapper层");
28         Map<String,Object> resultMap=new HashMap<>();
29         resultMap.put("userList",userList);
30         return resultMap;
31     }
32 }

UserServiceImpl.java

 1 package com.wzz.service;
 2
 3 import java.util.Map;
 4
 5 /**
 6  * @ClassName IUserService
 7  * @Description TODO 用户业务层接口
 8  * @Author AZhen
 9  * Version 1.0
10  **/
11 public interface IUserService {
12     Map<String,Object> queryUserList();
13 }

IUserService.java

　　sql脚本仅结构，没有数据，自行添加

 1 /*
 2  Navicat Premium Data Transfer
 3
 4  Source Server         : ssm
 5  Source Server Type    : MySQL
 6  Source Server Version : 80011
 7  Source Host           : localhost:3306
 8  Source Schema         : ssm
 9
10  Target Server Type    : MySQL
11  Target Server Version : 80011
12  File Encoding         : 65001
13
14  Date: 02/08/2019 08:24:19
15 */
16
17 SET NAMES utf8mb4;
18 SET FOREIGN_KEY_CHECKS = 0;
19
20 -- ----------------------------
21 -- Table structure for tbuser
22 -- ----------------------------
23 DROP TABLE IF EXISTS `tbuser`;
24 CREATE TABLE `tbuser`  (
25   `id` int(11) NOT NULL AUTO_INCREMENT,
26   `uId` varchar(32) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL,
27   `userName` varchar(20) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL,
28   `password` varchar(50) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL,
29   `uName` varchar(20) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL,
30   `age` int(11) NULL DEFAULT NULL,
31   `sex` int(11) NULL DEFAULT NULL,
32   PRIMARY KEY (`id`) USING BTREE
33 ) ENGINE = InnoDB AUTO_INCREMENT = 19 CHARACTER SET = utf8 COLLATE = utf8_general_ci ROW_FORMAT = Dynamic;
34
35 SET FOREIGN_KEY_CHECKS = 1;
