Jumpserver的部署和使用

硬件配置: 2个CPU核心, 4G 内存, 50G 硬盘（最低）
操作系统: Linux 发行版 x86_64

Python = 3.6.x
Mysql Server ≥ 5.6
Mariadb Server ≥ 5.5.56
Redis

提前安装好docker环境

[root@jumpserver-no ~]# docker pull mysql:5.7
[root@jumpserver-no ~]# mkdir /iflytek/mysql/mysql.conf.d -pv
[root@jumpserver-no ~]# mkdir /iflytek/mysql/conf.d -p
[root@jumpserver-no ~]# mkdir /iflytek/mysql/data
[root@jumpserver-no mysql]# cat /iflytek/mysql/mysql.conf.d/mysqld.cnf
# Copyright (c) 2014, 2016, Oracle and/or its affiliates. All rights reserved.
#
# This program is free software; you can redistribute it and/or modify
# it under the terms of the GNU General Public License, version 2.0,
# as published by the Free Software Foundation.
#
# This program is also distributed with certain software (including
# but not limited to OpenSSL) that is licensed under separate terms,
# as designated in a particular file or component or in included license
# documentation.  The authors of MySQL hereby grant you an additional
# permission to link the program and your derivative works with the
# separately licensed software that they have included with MySQL.
#
# This program is distributed in the hope that it will be useful,
# but WITHOUT ANY WARRANTY; without even the implied warranty of
# MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
# GNU General Public License, version 2.0, for more details.
#
# You should have received a copy of the GNU General Public License
# along with this program; if not, write to the Free Software
# Foundation, Inc., 51 Franklin St, Fifth Floor, Boston, MA  02110-1301 USA

#
# The MySQL  Server configuration file.
#
# For explanations see
# http://dev.mysql.com/doc/mysql/en/server-system-variables.html

[mysqld]
pid-file    = /var/run/mysqld/mysqld.pid
socket        = /var/run/mysqld/mysqld.sock
datadir        = /var/lib/mysql
#log-error    = /var/log/mysql/error.log
# By default we only accept connections from localhost
#bind-address    = 127.0.0.1
# Disabling symbolic-links is recommended to prevent assorted security risks
symbolic-links=0
[root@jumpserver-no mysql]# cat /iflytek/mysql/conf.d/mysql.cnf
[mysql]
default-character-set=utf8
[root@jumpserver-no ~]# docker run -it -d -p 3306:3306 -v /iflytek/mysql/mysql.conf.d/mysqld.cnf:/etc/mysql/mysql.conf.d/mysqld.cnf -v /iflytek/mysql/conf.d/mysql.cnf:/etc/mysql/conf.d/mysql.cnf -v /iflytek/mysql/data/:/var/lib/mysql -e MYSQL_ROOT_PASSWORD="Liu@2020" mysql:5.7
9c7b2bc71c84137b10430d9f0e41f80ec63997e65390e1a64160dffcef853c64
[root@jumpserver-no mysql]# yum install mysql-client
[root@jumpserver-no mysql]# mysql -uroot -pLiu@2020 -h172.31.242.80
mysql: [Warning] Using a password on the command line interface can be insecure.
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 2
Server version: 5.7.31 MySQL Community Server (GPL)

Copyright (c) 2000, 2020, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type ‘help;‘ or ‘\h‘ for help. Type ‘\c‘ to clear the current input statement.

mysql> show databases;
+--------------------+
| Database           |
+--------------------+
| information_schema |
| mysql              |
| performance_schema |
| sys                |
+--------------------+
4 rows in set (0.00 sec)

mysql> show global variables where variable_name like ‘character%‘;
+--------------------------+----------------------------+
| Variable_name            | Value                      |
+--------------------------+----------------------------+
| character_set_client     | latin1                     |
| character_set_connection | latin1                     |
| character_set_database   | latin1                     |
| character_set_filesystem | binary                     |
| character_set_results    | latin1                     |
| character_set_server     | latin1                     |
| character_set_system     | utf8                       |
| character_sets_dir       | /usr/share/mysql/charsets/ |
+--------------------------+----------------------------+
8 rows in set (0.00 sec)

mysql> create database jumpserver default charset ‘utf8‘ collate ‘utf8_bin‘;
Query OK, 1 row affected (0.00 sec)

mysql> grant all on jumpserver.* to ‘jumpserver‘@‘%‘ identified by ‘Liu@2020‘;
Query OK, 0 rows affected, 1 warning (0.00 sec)
