简单登陆UI设计

 1 import android.os.Bundle;
 2 import android.app.Activity;
 3 import android.content.Context;
 4 import android.content.Intent;
 5 import android.content.SharedPreferences;
 6 import android.view.Menu;
 7 import android.view.View;
 8 import android.view.View.OnClickListener;
 9 import android.widget.Button;
10 import android.widget.CheckBox;
11 import android.widget.EditText;
12 import android.widget.Toast;
13
14 public class MainActivity extends Activity {
15     private Button  logIn;
16     private CheckBox rember,auto;
17     private EditText name,password;
18     private SharedPreferences test;
19     private SharedPreferences.Editor editor;
20     private boolean haved;
21     @Override
22     protected void onCreate(Bundle savedInstanceState) {
23         super.onCreate(savedInstanceState);
24         setContentView(R.layout.activity_main);
25
26         logIn= (Button) findViewById(R.id.button1);
27         rember=(CheckBox) findViewById(R.id.remberFlag);
28         auto=(CheckBox)    findViewById(R.id.autoRunFlag);
29         name=(EditText) findViewById(R.id.name);
30         password=(EditText) findViewById(R.id.password);
31         final Intent intent=new Intent(MainActivity.this,NewMainActivity.class);
32         //打开 或 创建一个名为UserData的xml文件
33         test=getSharedPreferences("UserData", Context.MODE_PRIVATE);
34         editor=test.edit();
35
36         if(test.getBoolean("auto",false)!=false)
37         {
38             startActivity(intent);
39         }
40
41         if(test.getBoolean("rember", false)!=false)
42             {
43                 String temp;
44                 if((temp=test.getString("name", null))!=null)
45                     name.setText(temp);
46                 if((temp=test.getString("password",null)) != null)
47                     password.setText(temp);
48                 rember.setChecked(true);
49                 haved=true;
50             }
51
52         logIn.setOnClickListener(new View.OnClickListener() {
53             @Override
54             public void onClick(View v) {
55                 if(haved == false )
56                 {
57                     if(rember.isChecked())
58                     {
59                         editor.putBoolean("rember", true);
60                         editor.putString("name", name.getText().toString());
61                         editor.putString("password", password.getText().toString());
62                         editor.commit();
63                     }
64                     if(auto.isChecked()==true)
65                         editor.putBoolean("auto", true);
66                 }
67                 startActivity(intent);
68             }
69         });
70     }
71 }

 1 <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
 2     xmlns:tools="http://schemas.android.com/tools"
 3     android:layout_width="match_parent"
 4     android:layout_height="match_parent"
 5     android:paddingBottom="@dimen/activity_vertical_margin"
 6     android:paddingLeft="@dimen/activity_horizontal_margin"
 7     android:paddingRight="@dimen/activity_horizontal_margin"
 8     android:paddingTop="@dimen/activity_vertical_margin"
 9     tools:context=".MainActivity" >
10
11     <EditText
12         android:id="@+id/name"
13         android:layout_width="match_parent"
14         android:layout_height="wrap_content"
15         android:layout_alignLeft="@+id/password"
16         android:layout_alignParentTop="true"
17         android:layout_marginTop="16dp"
18         android:ems="10" />
19
20     <EditText
21         android:id="@+id/password"
22         android:layout_width="match_parent"
23         android:layout_height="wrap_content"
24         android:layout_below="@+id/name"
25         android:layout_centerHorizontal="true"
26         android:layout_marginTop="18dp"
27         android:ems="10" >
28
29         <requestFocus />
30     </EditText>
31
32     <Button
33         android:id="@+id/button1"
34         android:layout_width="wrap_content"
35         android:layout_height="wrap_content"
36         android:layout_alignLeft="@+id/password"
37         android:layout_below="@+id/password"
38         android:layout_marginLeft="16dp"
39         android:text="登陆" />
40
41     <CheckBox
42         android:id="@+id/autoRunFlag"
43         android:layout_width="wrap_content"
44         android:layout_height="wrap_content"
45         android:layout_alignLeft="@+id/password"
46         android:layout_below="@+id/button1"
47         android:text="自动登陆" />
48
49     <CheckBox
50         android:id="@+id/remberFlag"
51         android:layout_width="wrap_content"
52         android:layout_height="wrap_content"
53         android:layout_alignBaseline="@+id/autoRunFlag"
54         android:layout_alignBottom="@+id/autoRunFlag"
55         android:layout_alignRight="@+id/password"
56         android:text="记住密码" />
57
58 </RelativeLayout>

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context=".MainActivity" >

    <RatingBar
        android:id="@+id/ratingBar1"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentTop="true"
        android:layout_centerHorizontal="true"
        android:layout_marginTop="170dp" />

</RelativeLayout>

 <activity
            android:name="com.example.log_in.NewMainActivity"
            android:label="second_activity" >
        </activity>
