链接脚本使用----- 将二进制文件作为一个段

   1: .section .piggydata,#alloc

   2: .globl    input_data

   3: t_data:

   4: .incbin    "arch/arm/boot/compressed/piggy.gzip"

   5: .globl    input_data_end

   6: t_data_end:

   1: #include <stdio.h>

   2:

   3: extern unsigned int __peng_start;

   4: extern unsigned int __peng_end;

   5:

   6: char *p = (char *)(&__peng_start);

   7: //我们要获取__peng_start的存放地址，作为字符串首地址，或者数组名来使用。

   8: int main(int argc, const char *argv[])

   9: {

  10:     int i;

  11:     unsigned int len = 0;

  12:

  13:     len = (unsigned int)(&__peng_end) - (unsigned int)(&__peng_start);

  14:

  15:     printf("len = %x\n", len);

  16:

  17:     printf("%p\n", &__peng_start);

  18:     printf("%p\n", &__peng_end);

  19:

  20:     for(i=0; i<len; i++)

  21:     {

  22:         if (i % 16 == 0)

  23:         {

  24:             printf("\n");

  25:         }

  26:         printf("%3x ", *p++&0xff);

  27:     }

  28:

  29:

  30:     return 0;

  31: }

   1: OUTPUT_FORMAT("elf32-i386", "elf32-i386",

   2:           "elf32-i386")

   3: OUTPUT_ARCH(i386)

   4: ENTRY(_start)

   5: SEARCH_DIR("/usr/i486-linux-gnu/lib32"); SEARCH_DIR("/usr/local/lib32"); SEARCH_DIR("/lib32"); SEARCH_DIR("/usr/lib32"); SEARCH_DIR("/usr/i486-linux-gnu/lib"); SEARCH_DIR("/usr/local/lib"); SEARCH_DIR("/lib"); SEARCH_DIR("/usr/lib");

   6: SECTIONS

   7: {

   8:   /* Read-only sections, merged into text segment: */

   9:   PROVIDE (__executable_start = SEGMENT_START("text-segment", 0x08048000)); . = SEGMENT_START("text-segment", 0x08048000) + SIZEOF_HEADERS;

  10:   .interp         : { *(.interp) }

  11:   .note.gnu.build-id : { *(.note.gnu.build-id) }

  12:   .hash           : { *(.hash) }

  13:   .gnu.hash       : { *(.gnu.hash) }

  14:   .dynsym         : { *(.dynsym) }

  15:   .dynstr         : { *(.dynstr) }

  16:   .gnu.version    : { *(.gnu.version) }

  17:   .gnu.version_d  : { *(.gnu.version_d) }

  18:   .gnu.version_r  : { *(.gnu.version_r) }

  19:   .peng :

  20:   {

  21:      . = ALIGN(4);

  22:      __peng_start = .;

  23:      *(.peng);

  24:      __peng_end = .;

  25:      . = ALIGN(4);

  26:   }

  27:   .rel.dyn        :

  28:     {

  29:       *(.rel.init)

  30:       *(.rel.text .rel.text.* .rel.gnu.linkonce.t.*)

  31:       *(.rel.fini)

  32:       *(.rel.rodata .rel.rodata.* .rel.gnu.linkonce.r.*)

  33:       *(.rel.data.rel.ro* .rel.gnu.linkonce.d.rel.ro.*)

  34:       *(.rel.data .rel.data.* .rel.gnu.linkonce.d.*)

  35:       *(.rel.tdata .rel.tdata.* .rel.gnu.linkonce.td.*)

  36:       *(.rel.tbss .rel.tbss.* .rel.gnu.linkonce.tb.*)

  37:       *(.rel.ctors)

  38:       *(.rel.dtors)

  39:       *(.rel.got)

  40:       *(.rel.bss .rel.bss.* .rel.gnu.linkonce.b.*)

  41:       *(.rel.ifunc)

  42:     }

  43:   .rel.plt        :

  44:     {

  45:       *(.rel.plt)

  46:       PROVIDE_HIDDEN (__rel_iplt_start = .);

  47:       *(.rel.iplt)

  48:       PROVIDE_HIDDEN (__rel_iplt_end = .);

  49:     }

  50:   .init           :

  51:   {

  52:     KEEP (*(.init))

  53:   } =0x90909090

  54:   .plt            : { *(.plt) *(.iplt) }

  55:   .text           :

  56:   {

  57:     *(.text.unlikely .text.*_unlikely)

  58:     *(.text .stub .text.* .gnu.linkonce.t.*)

  59:     /* .gnu.warning sections are handled specially by elf32.em.  */

  60:     *(.gnu.warning)

  61:   } =0x90909090

  62:   .fini           :

  63:   {

  64:     KEEP (*(.fini))

  65:   } =0x90909090

  66:   PROVIDE (__etext = .);

  67:   PROVIDE (_etext = .);

  68:   PROVIDE (etext = .);

  69:   .rodata         : { *(.rodata .rodata.* .gnu.linkonce.r.*) }

  70:   .rodata1        : { *(.rodata1) }

  71:   .eh_frame_hdr : { *(.eh_frame_hdr) }

  72:   .eh_frame       : ONLY_IF_RO { KEEP (*(.eh_frame)) }

  73:   .gcc_except_table   : ONLY_IF_RO { *(.gcc_except_table .gcc_except_table.*) }

  74:   /* Adjust the address for the data segment.  We want to adjust up to

  75:      the same address within the page on the next page up.  */

  76:   . = ALIGN (CONSTANT (MAXPAGESIZE)) - ((CONSTANT (MAXPAGESIZE) - .) & (CONSTANT (MAXPAGESIZE) - 1)); . = DATA_SEGMENT_ALIGN (CONSTANT (MAXPAGESIZE), CONSTANT (COMMONPAGESIZE));

  77:   /* Exception handling  */

  78:   .eh_frame       : ONLY_IF_RW { KEEP (*(.eh_frame)) }

  79:   .gcc_except_table   : ONLY_IF_RW { *(.gcc_except_table .gcc_except_table.*) }

  80:   /* Thread Local Storage sections  */

  81:   .tdata      : { *(.tdata .tdata.* .gnu.linkonce.td.*) }

  82:   .tbss          : { *(.tbss .tbss.* .gnu.linkonce.tb.*) *(.tcommon) }

  83:   .preinit_array     :

  84:   {

  85:     PROVIDE_HIDDEN (__preinit_array_start = .);

  86:     KEEP (*(.preinit_array))

  87:     PROVIDE_HIDDEN (__preinit_array_end = .);

  88:   }

  89:   .init_array     :

  90:   {

  91:      PROVIDE_HIDDEN (__init_array_start = .);

  92:      KEEP (*(SORT(.init_array.*)))

  93:      KEEP (*(.init_array))

  94:      PROVIDE_HIDDEN (__init_array_end = .);

  95:   }

  96:   .fini_array     :

  97:   {

  98:     PROVIDE_HIDDEN (__fini_array_start = .);

  99:     KEEP (*(.fini_array))

 100:     KEEP (*(SORT(.fini_array.*)))

 101:     PROVIDE_HIDDEN (__fini_array_end = .);

 102:   }

 103:   .ctors          :

 104:   {

 105:     /* gcc uses crtbegin.o to find the start of

 106:        the constructors, so we make sure it is

 107:        first.  Because this is a wildcard, it

 108:        doesn‘t matter if the user does not

 109:        actually link against crtbegin.o; the

 110:        linker won‘t look for a file to match a

 111:        wildcard.  The wildcard also means that it

 112:        doesn‘t matter which directory crtbegin.o

 113:        is in.  */

 114:     KEEP (*crtbegin.o(.ctors))

 115:     KEEP (*crtbegin?.o(.ctors))

 116:     /* We don‘t want to include the .ctor section from

 117:        the crtend.o file until after the sorted ctors.

 118:        The .ctor section from the crtend file contains the

 119:        end of ctors marker and it must be last */

 120:     KEEP (*(EXCLUDE_FILE (*crtend.o *crtend?.o ) .ctors))

 121:     KEEP (*(SORT(.ctors.*)))

 122:     KEEP (*(.ctors))

 123:   }

 124:   .dtors          :

 125:   {

 126:     KEEP (*crtbegin.o(.dtors))

 127:     KEEP (*crtbegin?.o(.dtors))

 128:     KEEP (*(EXCLUDE_FILE (*crtend.o *crtend?.o ) .dtors))

 129:     KEEP (*(SORT(.dtors.*)))

 130:     KEEP (*(.dtors))

 131:   }

 132:   .jcr            : { KEEP (*(.jcr)) }

 133:   .data.rel.ro : { *(.data.rel.ro.local* .gnu.linkonce.d.rel.ro.local.*) *(.data.rel.ro* .gnu.linkonce.d.rel.ro.*) }

 134:   .dynamic        : { *(.dynamic) }

 135:   .got            : { *(.got) *(.igot) }

 136:   . = DATA_SEGMENT_RELRO_END (12, .);

 137:   .got.plt        : { *(.got.plt)  *(.igot.plt) }

 138:   .data           :

 139:   {

 140:     *(.data .data.* .gnu.linkonce.d.*)

 141:     SORT(CONSTRUCTORS)

 142:   }

 143:   .data1          : { *(.data1) }

 144:   _edata = .; PROVIDE (edata = .);

 145:   __bss_start = .;

 146:   .bss            :

 147:   {

 148:    *(.dynbss)

 149:    *(.bss .bss.* .gnu.linkonce.b.*)

 150:    *(COMMON)

 151:    /* Align here to ensure that the .bss section occupies space up to

 152:       _end.  Align after .bss to ensure correct alignment even if the

 153:       .bss section disappears because there are no input sections.

 154:       FIXME: Why do we need it? When there is no .bss section, we don‘t

 155:       pad the .data section.  */

 156:    . = ALIGN(. != 0 ? 32 / 8 : 1);

 157:   }

 158:   . = ALIGN(32 / 8);

 159:   . = ALIGN(32 / 8);

 160:   _end = .; PROVIDE (end = .);

 161:   . = DATA_SEGMENT_END (.);

 162:   /* Stabs debugging sections.  */

 163:   .stab          0 : { *(.stab) }

 164:   .stabstr       0 : { *(.stabstr) }

 165:   .stab.excl     0 : { *(.stab.excl) }

 166:   .stab.exclstr  0 : { *(.stab.exclstr) }

 167:   .stab.index    0 : { *(.stab.index) }

 168:   .stab.indexstr 0 : { *(.stab.indexstr) }

 169:   .comment       0 : { *(.comment) }

 170:   /* DWARF debug sections.

 171:      Symbols in the DWARF debugging sections are relative to the beginning

 172:      of the section so we begin them at 0.  */

 173:   /* DWARF 1 */

 174:   .debug          0 : { *(.debug) }

 175:   .line           0 : { *(.line) }

 176:   /* GNU DWARF 1 extensions */

 177:   .debug_srcinfo  0 : { *(.debug_srcinfo) }

 178:   .debug_sfnames  0 : { *(.debug_sfnames) }

 179:   /* DWARF 1.1 and DWARF 2 */

 180:   .debug_aranges  0 : { *(.debug_aranges) }

 181:   .debug_pubnames 0 : { *(.debug_pubnames) }

 182:   /* DWARF 2 */

 183:   .debug_info     0 : { *(.debug_info .gnu.linkonce.wi.*) }

 184:   .debug_abbrev   0 : { *(.debug_abbrev) }

 185:   .debug_line     0 : { *(.debug_line) }

 186:   .debug_frame    0 : { *(.debug_frame) }

 187:   .debug_str      0 : { *(.debug_str) }

 188:   .debug_loc      0 : { *(.debug_loc) }

 189:   .debug_macinfo  0 : { *(.debug_macinfo) }

 190:   /* SGI/MIPS DWARF 2 extensions */

 191:   .debug_weaknames 0 : { *(.debug_weaknames) }

 192:   .debug_funcnames 0 : { *(.debug_funcnames) }

 193:   .debug_typenames 0 : { *(.debug_typenames) }

 194:   .debug_varnames  0 : { *(.debug_varnames) }

 195:   /* DWARF 3 */

 196:   .debug_pubtypes 0 : { *(.debug_pubtypes) }

 197:   .debug_ranges   0 : { *(.debug_ranges) }

 198:   .gnu.attributes 0 : { KEEP (*(.gnu.attributes)) }

 199:   /DISCARD/ : { *(.note.GNU-stack) *(.gnu_debuglink) *(.gnu.lto_*) }

 200: }
